Cement Mill
Specification: φ1.83×7~φ4.6×14m
Processing capacity: 6.5-135t/h
Applied material: coal, cement, stone, sand, clay and ore
Applied area: portland cement making industry. Get price list
you can click the button and contact us.
Specialized Cement Mill
In the cement production line, we use cement crusher for cement crushing process, then we need cement mill for fine grinding stage. As a kind of cement grinding machine, Cement mill is the equipment used for grinding the hard , nodular clinker from the cement kiln into the fine grey powder that is cement.
Cement grinding mill is normally driven by electric motors. The output achieved by a cement mill system varies with the mill power, the fineness of the product and the hardness of the clinker.
Cement grinding mill is the last process of cement production, also the most power consumption process.
Its main function lies in grinding cement clinker (and gelling agent, performance adjusting grinding materials) into suitable particles (by fineness and specific surface area, etc), to form certain particle gradation, increasing its hydration area, accelerating the hydration speed, satisfying the slurry condensation and hardening requirements.
Henan Hongxing Mining Machinery Co., Ltd. is a professional manufacturer of full sets mining equipment including cement mills, stone production line, sand making production line and so on. Besides, we offer the most favorable cement mill price.
Future Prospect of Cement Ball Mill
Cement ball mill is not only suitable for over-flow grinding, but also applicable for cyclic close-flow grinding together with powder collector. The opportunities and challenges of the cement mill industry co-exsit today, although the overall size of milling machinery manufacturing industry has entered the ranks of the international producing countries, the overall competitiveness and development potential still can't compete with the developed countries. The current domestic high-end users and the basic components for products export mainly rely on imports.
This economic stimulus policy of development can avoid the economic crisis waves, and it makes the development of China's economy and the GDP stabilizing increase steadily. Some basic road and bridge construction of public facilities will bring significant step into the cement ball mill industry which makes cement ball mill industry usher in a new 'spring'.
Therefore, the development of cement mill in the future should focus on the revitalization of basic technology and infrastructure components to raise the level of independent development.
Parameters Type
Product specification (m) |
Milling form | Transmission form | Gear box | Motor power (kw) |
Production capacity (t/h) |
Total weight (t) |
|
Model | Speed reduction ratio | ||||||
Φ1.83×7 | Open flow | Brim | ZD60 | 4.5 | 245 | 6.5-8 | 43.8 |
Φ2.2×7.5 | Open flow | Brim | ZD70 | 5 | 380 | 8-10 | 64.8 |
Φ2.2×11 | Open flow | Brim | D110 | 35.5 | 630 | 12-13 | 104.6 |
Φ2.2×13 | Open flow | Brim | D110 | 35.5 | 630 | 16-18 | 114 |
Φ2.4×13 | Open flow | Brim | D110 | 35.5 | 800 | 20-23 | 130.6 |
Φ2.6×13 | Open flow | Brim | MFY100 | 19.5 | 1000 | 28-32 | 158 |
Φ3×9 | Circle flow | Brim | D125 | 41.2 | 1000 | 28-36.5 | 167 |
Φ3×11 | Circle flow | Brim | D140 | 42.8 | 1250 | 36-47 | 180 |
Φ3.2×13 | Open flow | Brim | D140 | 36.5 | 1600 | 45-50 | 225 |
Φ3.5×13 | Circle flow | Brim | JDX1000 | 5.84 | 2000 | 60-65 | 275 |
Φ3.8×13 | Open flow | Central shaft | MFY250 | 16.5 | 2500 | 60-62 | 320 |
Φ4.2×13 | Open flow | Central shaft | JQS3550 | 15.6 | 3530 | 85-87 | 380 |
Φ4.6×14 | Circle flow | Central shaft | JSI160-C | 14.6 | 4200 | 120-135 | 485 |
